RILE Machining Technology
and Assembly
Machining dimensions
01. A wide range of products and services
Complete solutions from one source
Thanks to our extensive machine pool and qualified personnel, we are able to take on system responsibility for your components and products.
Your advantages:
- Cost savings through reduction in in-house production depth
- Significantly reduced maintenance efforts
- Great logistics benefits and lower warehousing costs
- Low manufacturing costs thanks to shorter processing times
02. On-schedule - optimum availability
We use homogenous machining possibilities for products of all sizes to guarantee quick capacity availability and reliable delivery dates.
Your advantages:
- Short delivery times
- On-schedule delivery thanks to possibility of switching to backup production capacity
| RILE Flexible Manufacturing System (FMS) |
Working area machine |
Pallet Size Machine |
|---|---|---|
| Automation of Work pieces (Pallets) and Tools |
X = 1,250 mm Y = 1,000 mm Z = 1,000 mm |
800 x 800 x 125 mm for work pieces of up to: 1,540x1,250x1,200 mm other pallet sizes can be used in the RILE FMS at any time |
| Flexible Manufacturing System (FMS) |
Working area machine |
storage system, consisting of |
|---|---|---|
| Automation of two machining centers using a flexible tool and pallet system |
X = 1,000 mm Y = 800 mm Z = 1,000 mm |
2 setup stations and 26 pallet places |
| NC MILLING | X in mm | Y in mm | Z in mm |
|---|---|---|---|
| for carbon and ureol processing | 4800 | 1800 | 1200 |
| High speed cutting precision center | X in mm | Y in mm | Z in mm |
|---|---|---|---|
| for tool and mold making | 1050 | 800 | 560 |
| LATHE & MILLING | type | WORKING AREA Machine | Ø in mm |
|---|---|---|---|
| Gantry Milling Machine with 2 integrated rotary tables | gantry | X = 12000 mm Y = 5300 mm Z = 1600 mm |
5300 mm |
| CNC-Processing centers | x in mm | y in mm | z in mm |
|---|---|---|---|
| CNC large | 3500 | 2200 | 2000 |
| CNC large | 2800 | 2200 | 2100 |
| CNC large | 2600 | 1600 | 1800 |
| CNC middle | 1800 | 2100 | 1250 |
| CNC middle | 1600 | 1250 | 1000 |
| CNC middle | 1000 | 800 | 1100 |
| CNC middle | 1000 | 800 | 800 |
| CNC small | 800 | 800 | 710 |
| CNC-milling and turning centers | x in mm | y in mm | z in mm |
|---|---|---|---|
| CNC large | 4000 | 1300 | 1600 |
| CNC middle | 1250 | 1250 | 1000 |
| CNC middle | 1250 | 1000 | 1000 |
| New Invest | |||
|---|---|---|---|
| FMS - Mulit-Process Vertical Lathe Machining Center | type | Ø in mm | length in mm |
| automatic pallet changer | with 15 pallets | and two setup stations | |
| CNC (SOP 40/2020) | Double RAM | 2400 | 2500 |
| CNC (SOP 12/2021) | Single RAM | 2400 | 2500 |
| CNC (SOP 2022) | 2400 | 2500 |
| Lathe | type | Ø in mm | length in mm |
|---|---|---|---|
| CNC | vertical | 3750 | 3000 |
| CNC | vertical | 2800 | 2370 |
| CNC | vertical | 2500 | 2500 |
| CNC | vertical | 2000 | 1500 |
| CNC | vertical | 1000 | 800 |
| CNC | lining | 640 | - |
| Lathe | type | Ø in mm | length in mm |
|---|---|---|---|
| conventional | face plate | 1600 | - |
| conventional | centre lathe | 575 | 3000 |
| DRILLING | Ø in mm (for steel) | reach in mm | |
|---|---|---|---|
| conventional | 60 | 2000 |
| Boring Mill | x in mm | y in mm | z in mm |
|---|---|---|---|
| NC | 1000 | 1250 | 50 |
| Milling | x in mm | y in mm | z in mm |
|---|---|---|---|
| CNC | 3500 | 1000 | 750 |
| CNC | 2300 | 800 | 600 |
| CNC | 1525 | 600 | 610 |
| CNC | 760 | 510 | 610 |
| CNC | 800 | 560 | 510 |
| CNC | 400 | 400 | 400 |
| GEAR CUTTING | max. gear cutting Ø | max. work piece Ø | Table-Ø |
|---|---|---|---|
| Shaping | 1200 | 1500 | 900 |
| FLAT GRINDING MACHINE | x in mm | y in mm | z in mm |
|---|---|---|---|
| conventional | 2100 | 900 | 600 |
| PLAIN GRINDING MACHINE | Ø in mm | Length in mm | |
|---|---|---|---|
| CNC | 450 | 1600 |
| STEEL MANUFACTURE | welding places | saw in Ø mm | 1 crane |
|---|---|---|---|
| capacity | 6 | 400 | 10 tons |
| ASSEMBLY | assembly space in qm | 3 cranes | |
|---|---|---|---|
| capacity | 3500 | from 5-10 tons |
